Product certification
Product advantages
☑ IP68 dust and water proof☑ Simple wiring, no need to use crimping tools, just strip the wire and plug it in
☑ Diversified application scenarios
- 3D model
- Overview
- UL Electrical parameters
- Environmental conditions
- Environmental protection
- Electrical parameters
- Technical specification
3D model
Overview
| Flame retardant grade, in line with UL 94 | V0 |
UL Electrical parameters
| Rated current | 30A |
Environmental conditions
| Ambient temperature (operation) | -40 °C ~ 85 °C |
Environmental protection
| RoHS | No excessive harmful substances |
| REACh SVHC | Lead 7439-92-1 |
Electrical parameters
| Rated voltage | 1500V |
Technical specification
| IP class | IP68 |
Electrical parameter
| Rated voltage | 1500V DC | ||
| Rated current | 30A（4.0mm²/12AWG) , 35A（6.0mm²/10AWG） |
| Order number | 29030000044 |
| Packing unit | / |
| Minimum order quantity | / |
| Products weight (without packaging) | / |
