Product certification
Product advantages
☑ Push-In, spring connection more vibration resistance☑ Special structure coding, wiring guide identification
☑ With a fixed buckle, the connection is more secure and stable
- 3D model
- Wiring data
- UL Electrical parameters
- Connection capacity
- Electrical parameters IEC
- Item properties
- Material data
- Environmental data
3D model
Wiring data
| Strip length | 10~11mm |
UL Electrical parameters
| Rated voltage (Use Group B) | 600V |
| Rated current (Use Group B) | 20A |
Connection capacity
| Conductor cross section solid | 0.5~4mm² |
| Conductor cross section flexible | 0.5~4.0mm² |
| AWG | 20~12AWG |
Electrical parameters IEC
| Rated voltage(III/3) | 250V |
| Rated current | 32A |
| Rated voltage(III/2) | 400V |
Item properties
| Connection method | Push-in spring connection |
| Pitch | 9.75mm |
| Number of potentials | 3 |
| Pluggable or not | no |
Material data
| Environmental items | Compliant with REACH/RoHS |
Environmental data
| Ambient temperature (operation) | -40℃~105℃(depending on derating curve) |
VDE parameters
| Overvoltage category/Degree of pollution | III/3 | III/2 | II/2 |
| Rated voltage | 250V | 400V | / |
| Rated current | 32A | 32A | / |
| Cross section | / | 0.5~4mm² | / |
UL parameters
| Use group | B | C | D |
| Rated voltage | / | 600V | / |
| Rated current | / | 20A | / |
| AWG | / | 20~12AWG | / |
| Order number | 10080001222 |
| Packing unit | 30 |
| Minimum order quantity | |
| Products weight (without packaging) | 10.797 |
